Vertical Panels

The range of vertical panels SICH is composed of modular and self-supporting sandwich panels becoming an exible system, easy and quick to assemble, and with minimum maintenance.

General features

Phenolic resin finish

3 mm thick phenolic resin plate
Extruded polystyrene or rock wool core
Total thickness 60 mm
Standard size 1.290x3.000 mm
Color white SICH
SICH profiles specially designed to facilitate the union, the finish and the passage of the service facilities, facilitating the maintenance

Optional

Fireproof resin
Perimeter frame
Other thicknesses of phenolic resin on request
Other measures to be consulted
Other colors available

Lacquered sheet metal finish

0.5 mm thick lacquered steel sheet
Core in expanded polystyrene, rock wool or PIR
Total thickness 60 mm
Standard size 1.200x3.000 mm
Color white SICH
SICH profiles specially designed to facilitate the union, the finish and the passage of the service facilities, facilitating the maintenance

Optional

Other sheet thicknesses on request
Other measures to be consulted, up to 7 mt
Other colors available
Other coatings: PET, PVC or INOX
Tongue-and-groove joint for fire resistance
