Vertical Panels
The range of vertical panels SICH is composed of modular and self-supporting sandwich panels becoming an exible system, easy and quick to assemble, and with minimum maintenance.
General Features
Phenolic resin finish
- N3 mm thick phenolic resin plate
- NExtruded polystyrene or rock wool core
- NTotal thickness 60 mm
- NStandard size 1.290x3.000 mm
- NColor white SICH
- NSICH profiles specially designed to facilitate the union, the finish and the passage of the service facilities, facilitating the maintenance
Optional
- Fireproof resin
- Perimeter frame
- Other thicknesses of phenolic resin on request
- Other measures to be consulted
- Other colors available
Phenolic resin finish
- N0.5 mm thick lacquered steel sheet
- NCore in expanded polystyrene, rock wool or PIR
- NTotal thickness 60 mm
- NStandard size 1.200x3.000 mm
- NColor white SICH
- NSICH profiles specially designed to facilitate the union, the finish and the passage of the service facilities, facilitating the maintenance
Optional
- Other sheet thicknesses on request
- Other measures to be consulted, up to 7 mt
- Other colors available
- Other coatings: PET, PVC or INOX
- Tongue-and-groove joint for fire resistance
